DC Gear Motor with Encoder

• Manufacturer Part Number: D372
• Gearbox Type: Spur Gearbox
• Gear Ratio:1:70
• Geared Motor Reducer Voltage: 24V
• Reduced Motor Size: 37mm
• Application: Measuring Instrument Motor, Audio Equipment Motor, Medical Instrument Motor

Quantity:
  • D372(37mm)
  • I.CH

34mm DC Geared Motor integrated a 37mm spur gearbox of 1:70 gear ratio. It is a good solution to application that with limited space but low speed and high torque.
Specification

MODEL

VOLTAGE
V
NO LOAD Rated Load STALL
SPEED
rpm
CURRENT
A
SPEED
rpm
TORQUE
Kg.cm
CURRENT
A
Gear Ratio TORQUE
Kg.cm
CURRENT
mA
D372-03070+Encoder 24.0 71 0.08 62 3.0 0.2 1:70 16 1.2

Encoder Connection
Encoder接线图

Mechanical Dimensions
尺寸图


Encoder
111
Clutch

Motor
Brush Motor, Brushless Motor, Stepper Motor

Shaft
D-cut Shaft, H-cut Sahft, Rround Sahft
Full Datasheet
DC GEAR MOTOR.pdf
